Storch ProDist smart Handbuch Seite 105

1 Laser on
2 Reference point measurement top
3 Reference point measurement bottom
4 Reference point measurement thread
5 Reference point measurement folding end piece
6 Area/volume measurement (graphics area pictogram
and volume pictogram)
7 Indirect measurement (Pythagoras)
• Single Pythagoras (fig.)
• Double Pythagoras (fig.)
• Double Pythagoras (part height) (fig.)
• Angle measurement (fig.)
8 Mark measurement
9 Battery display status
10 Single distance measurement
11 Permanent measurement and min/max measurement
12 Device error message
13 Stored values/archive
14 Bluetooth on
15 Timer
16 Angle measurements
17 Intermediate value 1
18 Intermediate value 2
19 Intermediate value 3
20 Sum of the measured values
