Intended use
The sole purpose of the wave.com4 touch operating unit is to operate devices of the wave.com4 series. The
wave.com4touch operating unit can be used to its full extent in accordance with this provision.
Furthermore, the safety and usage information relating to the respectively connected devices applies.
2
General functional description
The wave.com4 touch operating unit automatically recognises the connected devices. The respective
menu points appear according to the devices recognised.
The devices must only be connected and disconnected when switched off.
The following operating modes and functions are available dependent on the connected devices. See also the
table of available functions:
•
Finnish operation
•
Climate operation
•
Infrared operation
•
Sound and light effects
•
Fan
•
Cabin light
•
Programmes
The supply can be executed via one or several of the devices listed below:
•
wave.com4 basic module (Finnish sauna)
•
wave.com4 basic module with add-on module (combi sauna)
•
wave.com4 Infra
Table of available functions:
Function
device
WC4-B-L
WC4-B-L +
WC4-H-PCB +
WC4-B-L +
WC4-H-PCB +
WC4-H-F2
WC4-B-L +
WC4-H-PCB +
WC4-H-H
WC4-B-L +
WC4-H-PCB
+ WC4-H-F2 +
WC4-H-H
WC4-IRX-P
WC4-SL-L
1
External loudspeaker 8 Ohm necessary – not contained in scope of supply
The colour lamp is used as a loudspeaker. See also sound&light connection – only for qualified personnel.
2
3
For WC4-IRX-P and WC4-B-L combinations, it can be selected in the system parameters which device cont-
rols the cabin light.
4
For WC4-IRX-P and WC4-B-L combinations it can be selected in the system parameters which device cont-
rols the fan.
5
The bench sensor must be activated in the system parameters.
