Recessed BINOPTIC or TEMPOMATIC models (fig. E):
FOR WALLS
• Make a recessing space, minimum size 188 162 70mm, so that the bottom of the spout is
approximately 200mm above the washbasin surface.
• Allow a recess for the water supply pipes and electrical supply to connect to the electronic housing.
• Solder two Ø12mm pipes onto the connectors. It is possible to connect the water supply to the top
of the box by turning it upside down.
• Cover with a Ø18mm sheath.
• Push the 4 mounting brackets on the housing gently towards the rear. Two holes in the bottom
of the stainless steel housing will allow its eventual attachment via the base.
• Seal the housing unit, tubes and the sheath.
• Seal the inside and lower edge of the housing unit with mastic to prevent any water leaking
into the wall. Position the silicone seal behind the stainless steel wall plate to ensure a waterproof seal
between the wall plate and the wall. Leave a drainage point to allow any residual water to drain away.
FOR DRY WALLS
• To attach the housing unit using the 4 mounting brackets, strengthen the dry wall with 2 support rails.
• Seal the inside and lower edge of the box with mastic to prevent any water leaking into the wall.
Position the silicone seal behind the stainless steel wall plate to ensure a waterproof seal
between the wall plate and the wall. Leave a drainage point to allow any residual water to drain away.
FIXING THE COVER
• Once the wall has been finished, attach the rails onto the stainless steel case with 4 screws,
ensuring that they are level.
• Install the hydraulic unit.
• Feed the sensor and solenoid valve cables through the sheath.
• Connect the flexible to the spout and the solenoid valve.
• Snap the cover onto the upper rail. After testing, tighten the 2 screws under the cover to tighten
in place using a 2.5mm Allen key.
• Connect the solenoid valve and complete the installation as shown in the CONNECTION section.
THE INSTALLER MUST ENSURE THAT:
• THE RECESSING AREA IS WATERPROOF TO PREVENT ANY INGRESS OF WATER;
• ANY WATER ACCIDENTALLY ENTERING THE RECESSING AREA (E.G. CONDENSATION, RUN OFF,
LEAKS, ETC.) HAS A DRAINAGE POINT TO PREVENT STAGNATION;
• THE INTEGRITY OF THE SEALS BETWEEN THE STAINLESS STEEL WALL PLATE AND THE WALL
OR THE WALL PLATE AND THE MIXER/TAP AT LEAST ONCE A YEAR, AND MORE FREQUENTLY
IF NECESSARY, AND MAKE GOOD IF NECESSARY.
If this advice is not followed, water may leak into the wall. DELABIE cannot be held responsible
for any ingress.
FOR FURTHER INFORMATION PLEASE CALL TECHNICAL SUPPORT (SEE BELOW FOR CONTACT DETAILS).
EN REMEMBER
• Our mixers/taps must be installed by profes
regulations and recommendations in your country,
• Sizing the pipes correctly will avoid problems o
(see calculation table in our brochure and online at
• Protect the installation with filters, water hamm
the frequency of maintenance (recommended pres
• Install stopcocks close to the mixer/tap to facilit
• The pipe work, stopcocks, bib taps and all sanitary
and more frequently if necessary.
CONNECTION
• Respect the direction of the water flow (see a
• Install the filters supplied to protect the soleno
• Connect the solenoid valve(s) to the terminal EV (fi
- RED wire(s): EV+ terminal
- BLUE wire(s): EV- terminal
• Connect the sensor cable to the BMR terminal (fig
- WHITE wire: terminal B
- BROWN wire: terminal M
- RED wire: terminal R
• Do not cut or lengthen the detector cable (50
• Connect to the power supply using an insulated tw
(2 1.5 or 2 1, ext. Ø7 - 8mm to ensure a water
electronic unit. A circuit breaker must be installed
(see ELECTRICAL SUPPLY section).
• Mount the wall unit under the washbasin at least 5
facing downwards.
• Tighten the nuts on the compression glands.
• Replace the fixing screws, cover and seal then clo
HOW THE ELECTRONIC UNIT OPERA
• The YELLOW LED i (ALIM) is lit when the power
• The GREEN LED j (EV) is lit when the sensor de
the water flow. When the hands are removed and a
and the GREEN LED goes out.
• The RED LED h (SECU) is lit and the flow of wate
object) continuously for 45 seconds; the anti-bloc
are/is removed the system is reset and a new cycl
• For the electronic unit to operate correctly the amb
