NEC MultiSync M-Serie Handbuch Seite 22

E - 16
Sides Tilt (parallelogram): increases or decreases the tilt of the sides
either to the left or right.
Sides Align (trapezoidal): increases or decreases the bottom of the
screen to be the same as the top.
Rotate (raster rotation): rotates the entire display clockwise or counter
clockwise.
Note on Controls in the Geometry Controls Menu:
EXIT: exits to the main menu.
Cursor / : moves the highlighted area up/down to select one of the
choices.
Cursor +/-: moves the bar in the + or – direction to increase or decrease
the adjustment.
RESET: resets the current highlighted control to the factory setting.
Tools
Provides a list of optional adjustments which include the following:
Surround Mode: Provides 4 preset sound settings for various
applications.
–
Voice/Standard Mode: For use with standard applications and
telephony functions. This mode is factory preset and will
remain as the primary setting unless another setting is selected.
–
Music/Game Mode: Maximizes the treble setting.
–
Movie/TV Mode: Maximizes the bass setting
–
Mono to Stereo Mode: Converts the mono input to stereo
sound for a simulated surround effect.
This bar provides adjustment for changing the level of sound effects,
acting as an equalizer.
NOTE: Select desired setting based upon your application.
Language: OSM menus are available in 6 languages.
Tools
