E - 8
Connection to Your Personal Computer
The MultiSync M Series color monitor complements NEC computers,
PC compatibles, Macintosh and Macintosh compatibles.
For the PC:
Your system has one of two configurations:
–
the video controller is built into the computer
–
the video controller is in the form of a display card (sometimes
referred to as the graphics card, video adapter or graphics board)
Both configurations have a video connector (or a CRT PORT on laptop
computers). If you are not sure which port is the video connector, please
consult your computer or display card manual.
For the Mac:
With the optional MultiSync M Series Macintosh Cable Adapter, the
MultiSync M Series color monitor is compatible with Macintosh
computers, as well as Macintosh clones.
NOTE: Power Macintosh 6100/60 users need to use the Apple HDI-45
cable adapter in conjunction with the appropriate MultiSync Cable
Adapter when connecting a MultiSync monitor.
The MultiSync M Series Macintosh Cable Adapter allows you to
change between 640 x 480, 832 x 624, 1024 x 768 and (1152 x 870:
only for M700) screen resolutions without restarting your system, if the
video port supports these modes. You will connect your MultiSync M
Series monitor one of two ways to your Macintosh computer:
–
On-board video port
–
NuBus, PDS or PCI display card
Both configurations should have the same style video connector. If you
are not sure which port is the video connector, please consult your
computer or display card manual.
Please contact your local dealer for information about the Mac Adapter.
