Geometry Controls
Color Control
Color Presets 1 through 5, selects the desired color setting. The bar is
replaced by the color setting choice from 1 to 5. Each color setting is
adjusted at the factory to the stated degree Kelvin. If a setting is adjusted,
the name of the setting will change from degree Kelvin to Custom.
Color Gain: Increases or decreases red, green, or blue depending upon
which is selected. The change in color will appear on screen and the
direction (increase or decrease) will be shown by the bars.
Note on Controls in Color Control Menu:
EXIT: Exits to the main menu.
Cursor / :Moves the highlighted area up/down to select one of the
choices.
Cursor +/-: Moves the bar in the + or – direction to increase or decrease
the adjustment or selects the color setting (1 through 5).
RESET: Resets the current highlighted color setting to the factory
setting.
The current color settings on your monitor were determined by focus
groups and end users' panels to be the most popular settings for the
majority of applications. NEC's Color Control system allows you to
change your on-screen colours by adjusting the monitor's red, green and
blue color guns individually. You can adjust colours to suit your
individual needs or preferences. You can also access five industry
standard color temperature settings.
Geometry Controls
Geometry Controls Menu
The Geometry controls allow you to adjust the curvature or angle of the
sides of your display.
Sides ln/Out (pincushion): increases or decreases the curvature of the
sides either inward or outward.
Sides Left/Right (pincushion balance): increases or decreases the
curvature of the sides either to the left or right.
E - 15
