Connection to Your Personal Computer
To attach the MultiSync M Series monitor to your system, follow these
instructions:
1. Turn off the power to your computer and MultiSync monitor.
2. If necessary, install the display card. For more information,
refer to the display card manual.
3. For the PC: Connect the MultiSync M Series monitor's
video cable to the display card's connector on the computer.
Tighten screws on all connectors.
For the Mac: Connect the MultiSync M Series Macintosh
Cable Adapter to the monitor's connector on your computer.
Connect the MultiSync M Series monitor's signal cable to the
other end of the cable adapter. Tighten screws on all
connectors.
4. Locate the audio output connection on the component(s)
which will serve as the source(s) for the built-in speakers.
(The component(s) could be your system, CD-ROM, sound
card, etc.).
5. Once you have determined the source, identify the connector
present from the source and connect the appropriate end of
the stereo input cable.
6. Connect the other end of the stereo input cable to the input
marked "
Headphone
Headphones may be connected to the "Headphones" output on
the left of the monitor's bezel. "
are connected, the sound from the speakers will be disabled.
Headphones can be purchased from your local electronic store.
Microphone
To take advantage of the built-in microphone, a stereo-male
mini jack cable can be purchased from your local computer
dealer/electronic store. Connect one end of the stereo-male
mini jack cable to the microphone (MIC IN) input on the rear
" on the rear of the monitor.
" While the headphones
E - 9
