DESCRIPTION OF THE DEVICE

7
8
9
10
(14) DMX output
(15) DMX input
(16) Power input
(17) Power output
(18) Power switch
(19) Fuseholder
11 12 13
1
2
3
4
5
6
DMX OUT DMX IN
14 15 16 17 18 19
24/36
(1) Lens
(2) Projector head
(3) TILT safeguard
(4) Yoke
(5) PAN safeguard
(6) Transport handle
(7) Base
(8) DMX indicator
(9) USB port for QuickDMX
receiver
(10) Error indicator
(11) LCD
(12) Operating buttons
(13) Rubber foot
OFF
POWER IN
100-240V ~
50/60 Hz
ON
POWER OUT T3.15A/250V
