Product features

LED moving head spot with color wheel, static and rotating gobo wheel, prism, frost, focus and zoom
• Equipped with a cold white 200 W COB LED
• Positioning within 540° PAN and 270° TILT
• Exact positioning via 16 bit PAN/TILT movement resolution
• Auto, music, master/slave and DMX mode
• Sound-control via built-in microphone
• Color wheel with 9 dichroic color filters and white
• Rainbow effect with adjustable speed in both directions
• Rotating 3-facet prism
• The prism rotates in both directions and at different speeds, prism index function
• Gobo-wheel 1 with 9 static metal gobos and open
• Gobo-wheel 2 with 7 rotating gobos and open
• All rotating gobos can be interchanged
• Slot-in gobo system for exchanging gobos without tools
• With gobo shake function
• Frost-filter
• Strobe effect with 1-18 flashes per second
• Internal programs
• Dimmer
• Dimmer speed (step response) adjustable
• Motorized focus
• Motorized zoom with 8-22° beam angle
• Fan-cooled
• Automatic position correction
• Supports QuickDMX - the wireless DMX system from Eurolite
• Built-in phantom-powered USB port for QuickDMX receivers (accessories)
• Control board with LCD and foil-keyboard for adjusting the DMX-starting address, PAN/TILT-Reverse,
Program, Reset
• Switch-mode power supply for operation between 100 and 240 volts
• P-Con terminals for power linking up to 8 units
• Additional rubber feet when the spot shall be positioned on the floor
• Projection: flicker-free
