Vertical movement (TILT)
Push slider up in order to move the mirror vertically (TILT). Gradual mirror adjustment
3
0 255
from one end of the slider to the other (0-255, 128-center). The mirror can be stopped at
any position you wish.
TILT-movement with 16-bit resolution
4
0 255 Fine indexing
PAN/TILT speed
5
0 255 Decreasing speed
Shutter, Strobe
0 3 Shutter closed
6
4 251 Strobe-effect with increasing speed
252 255 Shutter open
Dimmer intensity
7
0 255 Gradual adjustment of the dimmer intensity from 0 to 100 %
Color Wheel
0 4 White
5 9
White + red
10 14 Red
15 19 Red + green
20 24 Green
25 29 Green + blue
30 34 Blue
35 39 Blue + orange
40 44 Orange
45 49 Orange + purple
8
50 54 Purple
55 59 Purple + yellow
60 64 Yellow
65 69 Yellow + light green
70 74 Light green
75 79 Light green + pink
80 84 Pink
85 89 Pink+ light blue
90 94 Light blue
95 99 Light blue + white
100 182 Forwards rainbow effect with decreasing speed
183 255 Backwards rainbow effect with increasing speed
Static gobo-wheel, gobo shake
0 9
Open
10 19 Gobo 1
20 29 Gobo 2
30 39 Gobo 3
40 49 Gobo 4
50 59 Gobo 5
9
60 69 Gobo 6
70 79 Gobo 7
80 89 Gobo 8
90 99 Gobo 9
100 104 Gobo 1 shake with increasing speed
105 109 Gobo 2 shake with increasing speed
110 114 Gobo 3 shake with increasing speed
115 119 Gobo 4 shake with increasing speed
