Current Software Version
When the software of the fixture is booting, the current installed software version is shown for about 5
seconds in the display.
Functions of the Remote Control
Static Play: After pressing the button STATIC PLAY it's possible to set the values of Red (R), Green
(G), Blue (B) and Amber (A) with the buttons + and -. The intensity is set with the buttons DIMMER
(+) and DIMMER (-).
Triggering Effects: The preprogrammed effects can be used with the EFFECTKEY CONTROL
Buttons 01 - 06. The speed of the effects is controlled with the buttons SPEED (+) and SPEED (-).
HINWEIS: It is not possible to trigger the intensity of the effects with the DIMMER-Buttons.
Using Preset Colors: With the Color-Buttons 01 - 06 the preprogramed Colours can be used. The
intensity can be adjusted with the buttons DIMMER (+) and DIMMER (-).
The preprogrammed colors can be adjusted by pressing and holding the particular Color-Buttons
until the fixture starts blinking. After that it is possible to set the colour with the buttons + and - for Red
(R), Green (G), Blue (B), and Amber (A).
Downloaded from
www.Manualslib.com
STATIC PLAY
STATIC CONTROLS
R+
G+
R-
G-
EFFECTKEY CONTROLS
SPEED (+)
SPEED (-)
manuals search engine
ON/OFF
A+
B+
A-
B-
COLORKEY CONTROLS
DIMMER (-)
DIMMER (+)
