Miscellaneous Settings
MENU
The default password is: UP - DOWN - UP - DOWN - ENTER
KEY: In the menu KEY the password protection of the fixture is activated or deactivated. If set ON the
fixture is password protected when started. 30 seconds after the last setting the menu is locked
again. To be able to make changes in the menu the password UP - DOWN - UP - DOWN - ENTER
needs to be typed in.
UPLD: sends the user programs to connected slave fixtures.
REST: sets all editable settings back to factory default.
COLR: in this submenu a colour calibration is selected or deactivated. When RGBW is
selected, the maximum brightness values at DMX = 255 are limited to the values set in CAL2.
When UC is selected the Uniform-Colour factory calibration is used, which adjusts devices of
different generations. If the value is set OFF, the calibration is deactivated and the device reaches
the maximum brightness.
DIMX: controls different dimming speeds to simulate a halogen bulb (DIM4/DIM3/DIM2/DIM1/OFF).
CURV: In curve menu, the dimmercurves are set as shown below.
CURV dimming
(100%)
Downloaded from www.Manualslib.com
PERSON SET HSIC KEY
HSIC UPLD
HSIC REST
HSIC COLR
HSIC DIMX
HSIC CURV
HSIC DERR
HSIC SLCK
HSIC STRB
HSIC LIFE
1: OFF
1
2: CV1
2
3
3: CV2
4
4: CV3
manuals search engine
ON
OFF
SEND
****
REST
****
OFF
RGBW
UC
DIM1
DIM2
DIM3
DIM4
OFF
OFF
CV 1
CV 2
CV 3
SAVE
BLAK
OFF
ON
SPEC SPEC
CLAS
LONG
ECON
E-31
OK
