DERR: sets how the fixture responses if DMX-signal gets lost. Set SAVE to hold the last
received value or BLAK for blackout.
SLCK: Settings Lock. In this menu is set whether the menu SET is only accesable after entering the
password (ON) or without a password (OFF).
STRB: in the menu strobe a differentiation is made between standard stroboscope CLAS and
extended stroboscope SPEC. This setting only affects the DMX personalities TOUR, AR2.S
and TR16.
LIFE: sets if the full capacity of the battery is used for a max. runtime of approx. 12 hours (LONG) or
the economy mode for a longer battery lifetime with a max. runtime of approx. 10 hours (ECON).
Calibration and Whiteadjustment
MENU
In the menu CAL the calibrations and whiteadjustments can be set.
In the submenu CAL1 the preset colour temperatures for the white values are stored. These
are mixed from the parameters Red (RED), Green (GREN), Blue (BLUE) and Amber (AMBR).
In the menu CAL2, a custom colour calibration is stored which limits the maximum brightness of the
colour channels RGB at the DMX value "255".
NOTE: The maximum value can be limited to 0. In this case, a colour channel does not respond
to a sent DMX value, which can be misinterpreted as a device error.
To reset the changes made to the colour temperature presets to factory default, the setting
CALR needs to be confirmed with the default password UP - DOWN - UP - DOWN -
ENTER.
Wireless DMX Settings
MENU
WDMX: in the submenu ACTI, the integrated Wireless DMX Receiver can be activated (ON) or
deactivated (OFF).
REST: unlinks the existing connection and enables the pairing with another transmitter
Downloaded from www.Manualslib.com
PERSON CAL CAL1
