Csa Installation Drawing - 6331B - PR electronics 6331 Produkthandbuch

LERBAKKEN 10, 8410 RØNDE DENMARK.
Hazardous (Classified ) Location
IS,Class I, Division 1, Group A,B,C,D T4..T6
Ex ia IIC T4..T6 Ga
Class I, Zone 0, AEx ia IIC T4..T6 Ga
Terminal: 41,42,43,44
Connect to passive or
non-energy storing
devices such as RTD's
Resistors and
Thermocouples only.
Installation notes.
The Transmitter must be installed in a suitable enclosure to meet installation codes stipulated in The
Canadian Electrical Code (CEC).
Substitution of components may impair intrinsic safety.
Revision date:
2014-10-20
20
CSA Installation drawing 6331QC01
WWW.PRELECTRONICS.COM
T6: -40 ≤ Ta ≤ 60ºC
T4: -40 ≤ Ta ≤ 85ºC
44
43 13
+
12
42
11
41
CH1
6331B2A
Version Revision
V1R0
6331V107-DE
Non Hazardous Location
-
Barrier
Terminal:
11,13
Ui: 30 VDC
Ii: 120 mA
Pi: 0.84 W
Li: 10μH
Ci: 1.0nF
Co(Ca) > ∑(Ci+Ccable)
Lo(La) > ∑ (Li+Lcable)
Page:
1/2
