3.4 VALVE BODY SPECIFICATIONS

- Material:
- Types of connections:
- Nominal diameter (DN): DN8 to DN100
- Temperature of the conveyed medium: depends on the diaphragm material.
- Pressure class of the valve:
3233-3234-3235
Downloaded from www.Manualslib.com
•
Forged stainless steel (DIN 1.4435 BN2 / 316L according to ASME-BPE
1997).
•
Cast stainless steel (316L).
•
Rolled steel (316L).
•
butt-weld ends which conform to ISO 4200, SMS 3008, DIN 11850,
BS 4825-1 and JIS standards
•
Clamp ends which conform to BS 4825-3, ISO 2852, DIN 32676,
SMS 3017 standards
•
dairy pipe unions which conform to DIN 11851 or SMS 1145 standards
•
other connections on request.
•
P < 10 bar for DN8 to DN40
medium
•
P < 7 bar for DN50
medium
•
P < 5 bar for DN65 to DN100
medium
