3.1 GENERAL SPECIFICATIONS

The main advantages of the valve are the following:
- Heat number indicated on each valve to ensure the traceability of the material.
- Any mounting position.
- Any direction of flow.
- Perfect tightness due to diaphragm.
- Self-draining (valve 3233 only, see § 2.1).
- Small space requirement.
- Flow optimized design.
- Valve inside design optimized to reduce the turbulences to the minimum.
- Minimal charge loss.
- Internal mechanism adapted to the constraints of the food and drug industry.
- Steam sterilizable.
- Autoclavable.

3.2 MANUAL ACTUATOR SPECIFICATIONS

- Material: phenylene polysulphide (PPS), stainless steel or white epoxy coated cast
iron
- Handwheel diameter depending on the DN:
- Ambient temperature: +5 °C to +140 °C.

3.3 DIAPHRAGM SPECIFICATIONS

- Material:
•
•
- Temperature of the medium:
Downloaded from www.Manualslib.com
SPECIFICATIONS
DN 8 15
ø [mm]
35 80
PTFE/EPDM
elastomer (EPDM, FPM or CSM)
Material
PTFE ./ EPDM
EPDM
CSM
FPM
manuals search engine
20 25 40 50 80
80 80 114 114 225
Temperature [°C]
-10 to +130
-5 to +150
6
100
275
3233-3234-3235
