Using The Tap; Operation; Child Safety Lock; Menu - clage Zip HydroTap SPARKLING Gebrauchs- Und Montageanleitung

Zip HydroTap SPARKLING und BCS 120 / 125
®

5. Using the Tap

Boiling water lever
Red light
Boiling
Use these buttons to scroll the menu
Use these buttons to activate and deactivate
Downloaded from www.Manualslib.com
Note: If the drinking water system has not been used for several days, allow the
tap to run cold water for about five minutes.

Operation

Press the red lever to dispense boiling water. Pull the lever up to dispense boiling water
Chilled water lever
continually. The water will flow for 5 to 15 seconds. This time can be set in the menu. The
lever then has to be manually returned to the Off position.
Press the blue lever to dispense cold water. Pull the lever up to dispense cold water
continually. The water will flow for 5 to 15 seconds. This time can be set in the menu. The
lever then has to be manually returned to the Off position.
Press the red and blue levers simultaneously to dispense sparkling water with carbon
dioxide added. Pull the levers up to dispense sparkling water continually. The water will
flow for 5 to 15 seconds. This time can be set in the menu. The levers then have to be
manually returned to the Off position.
Red boiling water LED
• on all the time: boiling water is ready and can be dispensed.
White light Blue light
Filter status Chilled
• flashing: the water temperature is below the set value.
• flashing slowly: Sleep mode is enabled.
Blue cold water LED
• on all the time: temperature of cooled water is at the set temperature.
White filter LED
• flashing: the filter needs to be replaced. This LED starts flashing according to filter use

Child safety lock

A child safety lock can be enabled to prevent boiling water flowing out of the tap if the
boiling water control is accidentally operated. To draw boiling water when the child
safety lock is enabled, the Safety button has to be pressed and held down at the same
time as the red lever.
To enable the child safety lock, press the Safety button and the blue cold water lever at
the same time and hold for about ten seconds. The LED on the Safety button lights up
when the child safety lock is enabled.
To disable the child safety lock, press the Safety button and the blue cold water lever at
the same time and hold for about ten seconds. The LED on the Safety button goes out
when the child safety lock is disabled.
Child safety lock

Menu

Basic settings can be carried out in the menu. Use the 'Menu ∧' and 'Menu ∨' buttons
to browse through the various options. Adjustable parameters can be adjusted with
the aid of the Adjust ∧ and Adjust ∨ buttons. Parameters that are not adjustable are
indicated by '[Info]' in the list that follows.
• Litres filtered [Info]: quantity of water that has passed through the filter.
• Filter max. litres: the maximum quantity of water that can be filtered by the filter.
the selected program
• 'Day' off: deactivates the Zip HydroTap SPARKLING on the day of the week indicated
manuals search engine
and the filter capacity set in the menu.
Adjustable between 1,000 and 10,000 litres in 1,000 increments. The value that
should be set can be found in the filter data.
at the selected time to save energy.
24
