Zip HydroTap SPARKLING und BCS 120 / 125
®
B ( 2 : 1 )
4. Installation
7 6 5
7 6 5
Cut out a 10 mm slot for
the bolt
Fastening
bolt
View from below
Downloaded from www.Manualslib.com
4 3 2
8. Connect the undersink unit to the pressure reducer for the gas bottle using the
9. Connect the pressure reducer to the gas bottle:
Gas bottle with
self closing valve
Note: The carbon dioxide gas bottle must always be used in the upright posi-
tion to ensure that the pressure reducer operates correctly and thus ensure the
safety of the unit.
Note: The carbon dioxide gas bottle must not be exposed to heat. Please do not
Gas bottle with
exceed the maximum ambient temperature of 35°C. Provide cooling if neces-
hand weel
sary.
DATUM Name
16.07.2014 ruecker
Gezeichnet
Kontrolliert
Norm
Status Änderungen DATUM Name
4 3 2

Optional: Installing the tray

The tray (article number: 44101) is an accessory which can be used to install the tap
independently of a kitchen sink.
1. Ensure that a water supply, a drain, a socket fitted with at least a 10 A fuse and
2. Place the template supplied over the tray installation location.
Tap
3. Cut out the holes as indicated on the template.
4. Insert the tray. Place the plastic spacer between the worktop and the tray at the
Spacer
Tray
5. Install the tap as described from point 3 onwards of 'Installing the tap'.
6. If the drain bend is facing the wrong way, slacken off the fastening nut above the
7. Connect the drain bend to a siphon connecting sleeve, using a 22 mm diameter hose.
Spacer
S/S washer
Spider clamp
Fixing nut
35 mm hole
for tap
Drain Hole needed for tray
pipe bend recess 108 mm
manuals search engine
1
F
braided hose supplied.
E
a. Gas bottle with self closing valve: Turn the pressure adjusting screw on the
pressure reducer anticlockwise as far as it will go (no pressure). Then quickly screw
the gas bottle into the pressure reducer, as far as it will go.
D
b. Gas bottle with hand weel: Turn the pressure adjusting screw on the pressure
reducer anticlockwise as far as it will go (no pressure). Then connect the pressure
reducer to the gas bottle. Tighten the union nut moderately tight.
C
B
A
1
Zeichnung Gasflaschenkopf
A2
1
enough room for the undersink unit are all available at the tray installation location.
35 mm hole. Working from below, fasten the tray to the threaded rod using the
washer and nut supplied.
bend, turn it to the correct position and then tighten up the fastening nut again.
If no siphon connecting sleeve is available, use the snap connecting sleeve.
a. Place the snap connecting sleeve on the side of the siphon facing the sink. Drill a
13 mm diameter hole in the drain pipe behind the snap connecting sleeve for a
drain connection. Use a suitable sealant to make a watertight seal between the
snap connecting sleeve and the drain pipe.
22
