5. Using the Tap

Note: If the drinking water system has not been used for several days, allow the
tap to run cold water for about five minutes.

Operation

EN
Press the red lever to dispense boiling water. Pull the lever up to dispense boiling water
Boiling water lever Cold water lever
continually. The water will flow for 5 to 15 seconds. This time can be set in the menu.
The lever then has to be manually returned to the Off position.
Press the blue lever to dispense cold water. Pull the lever up to dispense cold water
continually. The water will flow for 5 to 15 seconds. This time can be set in the menu.
The lever then has to be manually returned to the Off position.
Press the red and blue levers simultaneously to dispense sparkling water with carbon
dioxide added. Pull the levers up to dispense sparkling water continually. The water will
flow for 5 to 15 seconds. This time can be set in the menu. The levers then have to be
manually returned to the Off position.
Red light
• On all the time: boiling water is ready and can be dispensed.
• Flashing: the water has not yet been heated to the set temperature.
Blue light
• On all the time: temperature of chilled water is at the set temperature.
• Flashing: the water has not yet been chilled to the set temperature.
White filter LED
White filter LED
• Flashing: the filter needs to be replaced. This LED starts flashing according to filter
use and the filter capacity set in the menu.

Child safety lock

A child safety lock can be enabled to prevent boiling water flowing out of the tap if the
red lever is accidentally operated. To dispense boiling water when the child safety lock
is enabled, press the Safety button and the red lever at the same time.
The child safety lock can be enabled and disabled either under Settings/Safety in the
menu or directly on the tap, as described below.
To enable the child safety lock, press the Safety button and the blue cold water lever at
the same time and hold for about ten seconds. The Safety button lights up when the
child safety lock is enabled.
To disable the child safety lock, press the Safety button and the blue cold water lever at
the same time and hold for about ten seconds. The Safety button light goes out when
the child safety lock is disabled.

Menu

The undersink unit has a touch screen which can be used to set and read the operating
parameters. The following settings can be carried out in the menu:
Safety button
'Language'
Select the language used in the menu.
'Information'
Shows data specific to the unit and any errors occurring.
'Install'
The steps that are necessary when using the unit for the first time can be viewed again
for maintenance purposes.
Flush filter – place the end of the hose located at the filter in a collecting container and
