Connect a Twisted-Pair Ethernet Cable
Connect the twisted-pair Ethernet (TPE) cable to one of the Ethernet ports on
the back panel. Each network interface configures itself automatically for
either 10-Mbps, 100-Mbps, or 1000-Mbps operation depending on network
characteristics.
1. Choose a network port, using the following table as a guide.
Ethernet Port PCI Bus/Clock Rate
1 PCI C/66 MHz
0 PCI D/33 MHz
Select the correct TPE connector for the interface you are installing. The server comes
with two TPE connectors on the back panel and one on the RSC card.
Your server may also include one or more TPE connectors provided via PCI Ethernet
interface cards.
OBP
Devalias Device Path
net1 pci@9, 600000/network@1
net0 pci@9, 700000/network@2
Chapter 3 Setup Procedures en-37
