Technical Parameters - GRAPHITE 58G945 Betriebsanleitung

When the filter has been dismantled use the wire hook to hold up the end of the suction line.
Be careful during fuel filter installation to prevent contamination from getting into the suction line.
OIL FILTER
● Unscrew oil filler plug (18).
● Use wire hook to remove the oil filter (
● Wash the oil filter in petrol or replace with a new one.
● Remove dirt from the tank.
● Install the oil filter in the tank.
● Tighten oil filler plug ( 18).
When putting the oil filter into the tank make sure it reaches front right corner.
IGNITION PLUG
To maintain reliable operation of the device, check condition of the ignition plug on a regular basis.
● Remove air filter lid ( 4).
● Remove air filter ( d).
● Remove wire ( i) from the ignition plug.
● Put on plug key (included) and unscrew the ignition plug (
● Clean and adjust spacing between contacts (0.65 mm) (replace ignition plug when necessary).
OTHER INSTRUCTIONS
Ensure there are no fuel leaks, loosened joints or damages of main parts, especially main handle joints and guide bar
fixing. When you find any damage, make sure it is repaired before next use of the chain saw.
All faults should be repaired by service workshop authorized by the manufacturer.
RATED PARAMETERS
Rated parameter
Engine displacement
Guide bar working length
Engine power
Engine speed with cutting system (maximum)
Idle rotational speed
Average fuel consumption
Fuel – petrol : oil for 2-stroke engines
Fuel tank capacity
Chain oil
Chain oil tank capacity
Carburettor
Ignition system
Ignition plug
Oil feed system
Chain wheel (teeth x pitch)
Type of guide bar
Size of guide bar
Type of chain
h) through the oil filler hole (fig. Y).
fig. Z).

TECHNICAL PARAMETERS

Petrol Chain Saw
29
Value
45 cc
405 mm
1.45 kW
7500 rpm
2800 rpm
0.9 l/h
25 : 1
550 ml
SAE 10W/ 30
260 ml
Walbro WT
Magneto
L8RTF (Champion RCJ7Y) (NGK BPRM8A)
Automated pump with controller
7T x 0.325" (8.25mm)
With chain toothed wheel
OREGON 445 mm standard
OREGON 21BP
