Explanation of used symbols
1. Do not put your hands or legs close to cutting parts
2. Danger of recoil
3. Exhaust gas poisoning hazard
4. Fire hazard
5. Use protective clothes
6. Use protective shoes
7. Use head, eyes and ears protection
8. Use protective gloves
9. Caution, use precaution measures
10. Switch off the engine and remove wire from the ignition plug before commencing any maintenance or repair. Read
instruction manual, observe warnings and safety conditions therein!
CONSTRUCTION AND USE
Petrol chain saw is a hand-held tool. It is driven by an air cooled, two-stroke combustion engine. Tool of this type is
designed for tasks in home garden. The saw can be used for cutting down trees, cutting branches, firewood, wood for
fireplace and other tasks where cutting wood is necessary. Petrol chain saw is a tool for amateur use only.
Use the device according to the manufacturer's instructions only.
DESCRIPTION OF DRAWING PAGES
Below enumeration refers to the device elements depicted on the drawing pages of this manual.
1. Throttle lever lock
2. Choke cable
3. Knob for air filter lid
4. Air filter lid
5. Front handle
6. Brake lever
7. Guide bar fixing nuts
8. Chain tension adjustment screw
9. Oil feed adjustment screw
10. Casing
11. Throttle lever
12. Main handle
13. Starter line
14. Ignition switch
15. Fuel filler plug
16. Carburettor adjustment screws, L and H
17. Low speed adjustment screw T
