Intended Use

The machine is intended for driving in and loosening screws
and bolts as well as for tightening and loosening nuts within
the respective range of dimension and performance. It must
only be connected to the power supply by means of a power
supply unit in the PUC-EXACT series.
This power tool is not intended for use as a drill; to avoid per-
sonal injury or damage to the tool, do not use any tool with a
shut-off clutch for drilling purposes.
The light of this power tool is intended to illuminate the power
tool's direct area of working operation and is not suitable for
household room illumination.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 Tool bit (e.g. bit)
2 Tool holder
3 Quick-change chuck ¼"
4 Marking ring
5 Rotational direction switch
6 LED indicator, tightening control

Technical Data

Corded Straight Screwdrivers with Push Start
Article number
– Europe: 0 602 495 ...
Rated voltage
Nominal current
No-load speed
Max. torque for hard/soft screwdriving application according to
ISO 5393
Rotational direction
Marking ring
Max. screw dia.
Weight according to EPTA-Procedure 01/2003
Degree of protection
Corded Straight Screwdrivers with Push Start
Article number
– Europe: 0 602 495 ...
Rated voltage
Nominal current
No-load speed
Max. torque for hard/soft screwdriving application according to
ISO 5393
Rotational direction
Marking ring
Max. screw dia.
Bosch Power Tools
7 Tool cord for connecting to the power supply unit PUC-
EXACT
8 Utility clip
9 On/Off switch
10 Torque selector switch
11 Socket sleeve on tool cord
12 Worklight
13 Connection socket on power supply unit PUC-EXACT
14 On/off switch on the power supply unit
15 Groove in the coupling of the tool cord 7
16 LED indicator, operational readiness
17 LED indicator, malfunction (overload)
18 Connection plug of the power cord
19 Mains cable
20 Power plug
21 Connection socket for power cord
22 Adjustment tool
23 Adjustment disc
24 Handle (insulated gripping surface)
The accessories illustrated or described are not included as stand-
ard delivery.
C-EXACT 1 C-EXACT 1
... 207
V 36
A 1.0
-1
min 1000
Nm 0.2–0.8
in-lbs 1.8–7.1
light green light green
M 2.5
kg 0.7
lbs 1.4
IP 20
C-EXACT 4 C-EXACT 4
... 205
V 36
A 1.0
-1
min 1000
Nm 0.5–3.5
in-lbs 4.4–31.0 4.4–31.0
grey
M 4
English | 15
C-EXACT 2
... 218 ... 208
36 36
1.0 1.0
500 500
0.2–0.8 0.5–2.0
1.8–7.1 4.4–17.7
grey
M 2.5 M 4
0.7 0.7
1.4 1.4
IP 20 IP 20
C-EXACT 4
... 206 ... 217
36 36
1.0 1.0
1000 275
0.5–3.5 0.5–3.5
4.4–31.0
grey grey
M 4 M 4
