Mounting the Monitor
Mount the monitor unit on the stand.
Attention
• Check that the mount lock indicator is in the locked position.
Mechanical Specifications (RX560 and GX560)
Dimensions (W x H x D)
Net weight
Height Adjustment
Tilt
Swivel (total)
Swivel (each monitor unit)
6
709.0 mm x 476.0 mm - 566.0 mm x 225.0 mm
(Tilt: 0°, swivel (each monitor unit) : 0°)
696.5 mm x 476.0 mm - 566.0 mm x 237.1 mm
(Tilt: 0°, swivel (each monitor unit) : 15°)
RX560: 17.3 kg
GX560: 17.1 kg
90 mm (Tilt: 0˚)
Up 25˚, down 5˚
40°
15°
: Locked
