3. Connect the USB cable when using RadiCS / RadiCS LE.
Attention
• In order to perform monitor quality control for the GX560, connect a PC with RadiCS / RadiCS LE installed
to . Refer to "2-2. Connecting Cables" in the Instructions for Use on how to connect cables.
4. Touch on the front of the monitor to turn on the power to the monitor.
The power switch indicator of the monitor lights up green.
5. Turn on the PC.
The screen image appears.
Note
• If the monitor does not operate correctly, refer to "No-Picture Problem" in the Instructions for Use.
●
Adjusting the Posture of Each Monitor
1. Adjust the swivel and horizontal positions.
Holding the top and bottom of the monitor unit with both hands, adjust the angle and position of each monitor
individually.
The swivel angle can be locked by turning the swivel lock screw clockwise to tighten it.
Note
• The swivel lock screw is not locked before shipment.
2. Adjust the rotation.
The space between monitors can be eliminated by turning the rotation screw. Adjust as necessary.
Attention
• Do not perform rotation by moving the monitors by hand.
Note
• Use a (#2) phillips head screwdriver for the swivel lock screw and rotation screw.
4
Connect to monitor Connect to PC
