Scheppach 5904605903 Originalanleitung Seite 18

Service information
Please note that the following parts of this
product are subject to normal or natural wear
■ STORAGE
If the plate compactor will not be used for a
period longer than 30 days, follow the steps
below to prepare your unit for storage.
1. Drain the fuel tank completely. Stored fuel
containing ethanol or MTBE can start to go
stale in 30 days. Stale fuel has high gum
content and can clog the carburetor and
restrict fuel flow.
2. Start the engine and allow it to run until it
stops. This ensures no fuel is left in the car-
buretor. Run the engine until it stops. This
helps prevent deposits from forming inside
the carburetor and possible engine damage.
3. While the engine is still warm, drain the oil
from the engine. Refill with fresh oil.
4. Allow the engine to cool. Remove the spark
plug and put 60 ml of SAE-30 of high quality
■ TRANSPORTATION
See technical data for the weight of the
machine. To avoid burns or fire hazards, let
engine cool before lifting/transporting machine
or storing indoors
GB
and that the following parts are therefore also
required for use as consumables.
engine oil into the cylinder. Pull the starter
rope slowly to distribute the oil. Replace the
spark plug.
m Remove the spark plug and drain all of
the oil from the cylinder before attempt-
ing to start the unit after storage.
5. Use clean cloths to clean off the outside of
the compactor and to keep the air vents free
of obstructions.
Lift unit by lift hook on roll cage. Use a reliable
chain, cable or strap of adequate lifting capac-
ity. The unit must be transported in the upright
position to prevent fuel from spilling. Do not
lay machine on its side or top.
18
Wear parts*: Spark plug, oil, belt, rubber mat
* Not necessarily included in the scope of
delivery!
m Do not use strong detergents or petro-
leum based cleaners when cleaning
plastic parts. Chemicals can damage
plastics.
6. Secure the handle with the lock pin as
shown.
7. Store your plate compactor in upright
position in a clean, dry building that has
good ventilation.
m Do not store compactor with fuel in a
non-ventilated area where fuel fumes
may reach flame, sparks, pilot lights or
any ignition sources. Use only approved
fuel containers.
Latch the handlebar in place with the lock pin
during lifting/transporting.
Secure or tie down unit using lift hook or roll
cage when transporting.
m Machine may fall and cause damage or
injury if lifted incorrectly. Lift by lift hook
only.
