Connect Switch Panel Cable together with the modular linking cable to
the control terminal block of the Master Unit. Fix this cable in the back
panel using a suitable cable gland (not supplied). Connect to other end of
the modular linking cable to the slave units in a similar fashion. Replace
the control housing of each unit and power up all units. Ensure that all
switch settings are functioning correctly.
Switch Panel
Installation
The backing box should be fixed to a suitable wall with appropriate
conduit used where applicable to carry the cable between the heater
and the switch panel. (see Fig. 8 for dimensions)
This cable used to connect the heater to the switch panel should have
sufficient cores (typically 5 core) to allow connection as per the enclosed
wiring diagram and be at least 1.0mm².
Test all switch settings once installation is complete.
Switch Panel Connections
Connections are made as shown in Fig. 10. (References listed below).
1 - FAN ON - OFF
2 - HEAT 1
3 - HEAT 2
T - TERMINAL BLOCK
SPC - SWITCH PANEL CABLE TO HEATER (NOT SUPPLIED)
Tip: When stripping back the switch panel cable make note of the numbering
or colours of each wire and their associated connections to the terminal
block.
Operation of switch panel
Switch on electrical supply (MAINS IN) to the heater. Switching the switch
marked 'I' energises the fan. The heat selection switches allow heat
settings to be chosen as shown below:
Settings - I
I +
I +
The desired heater setting can be obtained through switch selection.
Thermal Safety Cut-out
The power supply to the heating elements will be interrupted if one or a
combination of the following abnormal events occurs:
1. Air inlet or outlet grilles are obstructed.
2. Internal ventilation is impaired due to build up of dust and
fluff.
3. Blower unit stalls.
NOTE: Before re-setting the reason for activation must be determined
and corrective action taken.
To reset the thermal safety cut-out for the CFS60, CFS90 or CFS120
models, access reset buttons as shown in Fig. 11 and push in direction
of arrow. The CFS30 has an electrical reset cut-out which requires the
power supply to be removed for a short period of time to allow the cut-
out cool down. On return of the power supply, the heater should operate
normally.
Fan Only
Half Heat
Full Heat
- 2 -
Cleaning
WARNING: DISCONNECT SUPPLY before carrying out maintenance.
External appearance can be maintained by wiping occasionally with a
damp cloth. For stain removal, a weak soap solution can be applied with
a cloth and the surface wiped dry. Care must be taken to avoid any
moisture ingress into the product.
After Sales Service
Should you require after sales service or should you need to purchase
any spares, please contact the retailer from whom the appliance was
purchased or contact the service number relevant to your country on
the warranty card.
Please do not return a faulty product to us in the first instance as this
may result in loss or damage and delay in providing you with a satisfactory
service.
Please retain your receipt as proof of purchase.
