COUNTERS DESCRIPTION
This manual refers to a refrigeration unit suited for preserving frozen food products, whether packed or not; the
unit is available in the following versions:
REFRIGERATED PIZZA COUNTER
TN 700 Gastronorm 1/1
TN 800 (600X800mm)
•
2 doors - 3 doors - 4 doors.
• TN 700 EKO with and without neutral drawers.
•
TN 800 EN - MID with and without neutral drawers.
•
Granite working top with granite rear risers.
•
Fitted with blind doors or with glass doors with automatic magnetic door closing.
• With or without condensing unit.
•
Electronic controller and main switch.
•
Standard voltage 230V - 1P - 50Hz.
REFRIGERATED DISPLAYS
FOR INGREDIENTS
VR 4 - VR 3
The REFRIGERATED DISPLAYs FOR INGREDIENTS are available as follow:
• With or without glasses with GN basins support (GN basins not included).
• With condensing unit.
• Electronic controller and main switch.
Both refrigerated table versions have an external and internal structure made of stainless steel AISI Type 304, whereas
the outside parts, including the bottom, ceiling and the back are made of zinc-coated plate. The basin is insulated with
expanded polyurethane resin with a density of 38-42Kg./Mc. Power supplied with electric cable already provided by
the manufacturer.
The insulation of the basin is free of CFC in order to guarantee a low environmental impact.
ATTENTION
All operations regarding the points:
"1 COUNTER POSITIONING" Pag. 28
"2 ELECTRICAL CONNECTION AND EARTHING" Pag. 30
"3 CLEANING" Pag. 32
"5 MAINTANANCE - GARBAGE MANAGEMENT - DISPOSAL OF MATERIALS" Pag. 36
Must be carried out by high qualified technical staff.
Pizza Refrigerated Counters | User and Maintenance Manual | EN
LINE
EKO
EN - MID
LINE
GN 1/4 - GN 1/3
TEMPERATURE
-2; 0 / +8 °C
-2; 0 / +8 °C
TEMPERATURE
+2; 0 / +10 °C
27
