3.1 Technical data
PROFI SC
Max. flow rate
Max. pressure haed
Pum pm otor output
Pow er supply
Current consum ption m ax. per pum p
Operating voltage
Standby pow er input
Class of protection
Hydraulic fluid tem perature
Am bient tem perature
Installation
Width m m
Depth m m
Height m m
Pressure connection
Potable w ater connection
Supply pum p connection
Overflow
Breaktank
Weight em pty
Weight filled
3.2 Connection diagram
Seite 36
Page
9-90
14-90
~ 9 m³/h
~ 14 m³/h
90 m
92 m
2 x 1460 W
2 x 2000 W
3 x ~ 400V/50Hz
3,2 A
3,8 A
9V DC
2,8 W
IP 44
+5°C bis +35°C
+10°C bis +35°C
Indoor / Frost-free
800 mm
725 mm
1670 - 1690 mm
1 ½" AG
1 ½" AG
1 ¼" AG
1 ¼" AG
1 ¼" AG
1 ¼" AG
DN 100
200 L nominal
ca. 150 Kg
ca. 320 Kg
25-60
25-80
~ 25 m³/h
~ 25 m³/h
59 m
84 m
2 x 2210 W
2 x 3180 W
4,0 A
6,4 A
2" AG
2" AG
2" AG
2" AG
1 ½" AG
1 ½" AG
ca. 165 Kg
ca. 335 Kg
