Intewa PROFI SC 9-90 Installation Und Betriebsanleitung Seite 30

2.5 Control elements
You can also check the operation of the pump and the solenoid valve for potable
water supply over the control element.
For this:
• Press simultaneously the button 4 under the display "Quit" and the upper "Arrow" button
on the control unit, see figure 4
- This installation mode 1 is activated.
• After pressing the down „Arrow" button the display will switch into the Installation Mode
2, see figure 5.
• Button 1 "SP1":
By pressing the button, the submersible pump 1 is activated."
- SP1 display blinks during operation.
• Button2 "SP2":
By pressing the button, the submersible pump 1 is activated."
- SP2 display blinks during operation.
• Button 3 "SV":
By pressing the button, the solenoid valve for potable water is activated."
- SV display blinks during operation.
- Only possible if the level in the break tank is below the third reed switch for level
detection.
• Button 4 "Quit":
By pressing the button you will take back out of the installation mode.
fig. 4
Seite 30
fig. 5
