The home screen display may differ
according to its configuration.
Depending on your installation, some of
the functions described in this manual
may not be active.
The active function icons are
■
displayed at the top of the screen.
When your battery is low, the low
■
battery warning is displayed.
HVAC menu
Command sent to
the controller
Comfort temp. step
Lights ON
Lights / Blinds
control group
Lights OFF
Example:
Communicating
Comfort temp. step
Fan speed
Louver position
2
Display
Lights control menu Blinds control menu
++
Medium
4
Energy saving
After 30 minutes of inactivity, the
display will go blank.
To wake your remote control, press and
release any button on your remote
control.
Louver control menu
Low battery signal
Displayed value
- louver position
- comfort temperature
Louver position
Fan speed
▲ Raising blinds
▼ Lowering blinds
Non-communicating
Comfort temp.
Fan speed
Louver position
(Louver menu)
(optional)
20.5 °C
Low
Automatic
