If the lighting control option is enabled,
you may use the remote control to easily
turn the lights on and off.
To turn the lights on/off
Press the Menu button
■
Lights control menu.
Press the Fan speed button
■
the lighting group. The group number
will start flashing.
Once the lighting group is selected,
■
press to turn the lights ON or press
to turn the lights OFF.
The icon ON or OFF together with the
■
selected group will be displayed for
3 seconds to confirm the lights on/off
command.
If the blinds control option is enabled, you
may use the remote control to raise the
blinds all the way up to let the sunlight
enter your room or lower the blinds
completely to block the sunlight.
To set the position of blinds
Press the Menu button
■
Blinds control menu.
Press the Fan speed button
■
the blinds group. The group number
will start flashing.
Once the blinds group is selected, press
■
to raise the blinds or press
lower the blinds.
The icon ▲ or ▼ together with the
■
selected group will be displayed for
3 seconds to confirm the blinds raising/
lowering command.
Lighting Control
Example:
to access the
to select
Selecting all zones
(A – All zones)
Note: The number of lighting groups displayed
on the screen may differ depending on prior
configuration. "A" means that all lighting
groups are selected.
Blinds Control
Example:
to access the
to select Selecting one zone
(Zone No. 2)
Note: The number of blinds groups displayed
to
on the screen may differ depending on prior
configuration. "A" means that all blinds
groups are selected.
Lights ON
command sent to
all lighting groups
Raise blinds
command sent to
blind group No. 2
