Mod. 07000
7.3 Check
• check pushbutton panel
buttons: 1/2/3....
• Magnetic valves
VM
• Grinder
01
• Sensor ?lower
• Sensor? upper
• Water pump
00
• Grinder setting
• Heating/temp
00 0....
• Inputs/sensors
0111001
• Led+background
• EEPROM test
7.4 grinder setting
7.5 Reset water tank
7.7 prepaid
7.8 Software Version
8 VENDING MACHINE
8.1 key function
8.1.1 small cup
8.1.2 large cup
8.1.3 XL cup
8.1.4 strong
8.1.5 hot water
8.1.6 steam
8.1.7 instant coffee
7.3. Specifics on the menu functions
7.3.1. Auto on and auto off (menu n° 2.4.1./2.4.2.) if enabled, are used to automatically turn on and off the machine at the programmed time, to
program proceed as follows: press the enter key to change the turn on time, the flashing figure can be changed with the + and – keys then press enter
to confirm and then change the minutes.
7.3.2. Auto standby (menu n° 2.4.3.) when the function is enabled the machine goes off after the programmed time, to turn it on again just press any
key.
7.3.3. Cleaning (menu 3.2.) is used to start a cleaning program with the specific greaser removing tablets. Press enter on the display and the words
"insert tablet" will appear, open the front door and insert the tablet close the door and press enter to start the wash cycle (the cycle lasts 10 minutes),
at this point "cleaning in progress" will appear on the display, when "cleaning completed" appears on the display press enter to exit the wash cycle.
7.3.4. Lime removal (menu 3.3.) used to start the lime removal program of the hydraulic circuit. Fill the water tank and pour in the correct amount of
a lime removal product for coffee machines (see the instructions of the product you use), select the circuit where the lime will be removed (menu 3.3.1
coffee circuit, menu 3.3.2 steam circuit) then press enter, the words "lime removal in progress" will appear on the screen, the lime removal program
lasts 1 hour. At the end of the lime removal cycle the words "lime removal completed" will appear on the display then press enter.
7.3.5. These functions are protected by password and must not be changed for any reason, otherwise the correct operation of the machine could be
compromised.
7.3.6. These functions are only accessible to the technician and protected by password, they must absolutely not be changed by unauthorised person-
nel, otherwise the correct operation of the machine could be compromised.
Menu for technician (details in point 7.3.6)
