PE L1 L2 L3
Fig.18
Impianto elettrico luci
(optional)
light wiring system
Impianto elettrico Calpestio
(optional)
wiring system
Treadable
Impianto el. Pedana
platform wiring system
da Pedana
From platform
Fig.19
0596-M010-1
N
Pedana Pedana
Platform Platform
SX DX
F
da Pedana
From platform
SX DX
Impianto elettrico luci
(optional)
light wiring system
Impianto elettrico Calpestio
(optional)
wiring system
Treadable
Impianto el. Pedana
platform wiring system
