5.3 Fixing and mounting the casing
1) Fix the base of the panel in a protected area; we suggest using
round top Phillips recessed head screws of max. 6mm in diameter.
3) After the adjustments and settings, fix the cover using the provided screws.

6 Electrical connections

Gearmotor
Gearmotor featuring delayed action
on opening (M1)
FERNI
FROG
M1
When using only one motor (e.g. on one leaf gates), connect it up on W X Y (M2) regardless of
which side it is installed on – (fro FROG, if need be, invert connections X and Y).
FAST
ATI
KRONO
U V W X Y E1
Standard opening setup scheme in Came gearmotors.
2) Perforate the pre-punched holes and insert the cable glands with the
corrugated tubing for the electrical cables to travel through.
N.B.: the pre-punched holes have the following diameters: 23, 29 e 37 mm.
Be careful not to damage the control board inside the control panel!!
FERNI
Gearmotor featuring delayed action
on closing (M2)
FAST
KRONO
FROG
M2
ATI
