Scope of Supply

Scope of Supply Scope of Supply
Scope of Supply Scope of Supply
Infinity M with the possibility of connection to the Infinity M Infinity M Infinity M Infinity M
HydroModul system
or a separate connecting module or connector,
with or without pressure reducer (not supplied),
consisting of:
1 1 1 1 1 Outer casing (top section in brass)
2 2 2 2 2 Rotating knob
3 3 3 3 3 Crank
4 4 4 4 4 Transparent cylinder
- - - - - Filter element
5 5 5 5 5 Date ring
6 6 6 6 6 Waste water connection (HT connection or hose
nozzle)
7 7 7 7 7 Safety stop valve
8 8 8 8 8 Cover plate
necessary Accessories: necessary Accessories: necessary Accessories: necessary Accessories: necessary Accessories:
9 9 9 9 9 Connecting module / connector
