Start-up
6.2

Ceiling installation

For the installation on the ceiling, please proceed as fol-
lows:
• Disconnect the corresponding line of the
incoming Homematic IP wired bus.
• Select a mounting location at that point where
the bus cable is led out of the ceiling.
• Mark the two bore holes (G) to the mounting
location in a distance of 40 mm (see fig. 3).
• Drill the holes marked and insert the supplied
plugs (see figure 3).
If you are working with a stone wall, drill the
marked two 5 mm holes and insert the plugs
supplied. If you are working with a wooden wall,
you can pre-drill 1.5 mm holes to make screws
easier to insert.
Feed the bus cable through the cable bushing (F)
•
of the installation adapter (see figure 4).
• Mount the installation adapter by screwing the
supplied screws (3.0 x 30 mm) into the plugs (see
figure 5).
• To facilitate the connection of the bus line to the
terminals of the presence sensor, remove the
green push-in terminal from the device. Press the
latch on the back of the mounting plate next to
the lock symbol and slide the clamp out of the
