Maintenance and cleaning

10 Maintenance and cleaning
The product does not require any maintenance.
Enlist the help of an expert to carry out any
repairs.
Clean the device using a soft, lint-free cloth that is clean
and dry. Do not use any detergents containing solvents,
as they could corrode the plastic housing and label.
11

Technical specifications

Device short name:
Supply voltage:
Current consumption:
Standby power consumption: 45.6 mW (1.9 mA)
Cable type and cross section Rigid cable
Installation:
Degree of protection:
Protection class:
Ambient temperature:
Dimensions (ø x H)
Weight:
58
HmIPW-SPI
24 V , +5 % -20 %, SELV
DC
5 mA max.
0.12-0.50 mm²
only in normal commer-
cial switch boxes (device
boxes) in accordance
with DIN 49073-1 or in
the installation adapter.
IP20
III
-5 to +40 °C
100 x 45 mm
92 g
