Default Settings; Status Bar - Tylo SENSE COMBI Gebrauchsanweisung

2
Switch on the heater to remove any new paint odours
To remove "new paint odour" from the heater:
Heat to approx. 90°C for about one hour (see The section called
Use, Page 4).
A little smoke may appear.

Default settings

Using the control panel for the first time:
1. Check the heater manual for getting started and safety pre-
cautions.
2. Pass your hand over the screen to light it up.
3. Select region (Europe, USA, Other). Use UP and DOWN to
scroll through the menu. Confirm using OK (see Figure 2,
Page 2).
Figure 2: UP, DOWN and OK
4. Select language. Confirm with OK.
5. Enter current time. Confirm with OK.
6. Enter current date (yyyy-mm-dd). Confirm with OK.
7. Select System type (Timer-controlled, Monitored or
Private).
Key to system type:
System type Timer-controlled is used for systems in which
calendar programming or delayed start are required. Maxim-
um running time for this choice is 12 hours. After 12 hours, the
system must be shut down for at least 6 hours. A door contact
must also be connected to the sauna door to detect whether
the door is opened after the last shut-down.
System type Monitored is used for systems where there are
always personnel to monitor the sauna. No calendar program-
ming or delayed start can be used with this choice.
System type Private is used for private systems. Max. sauna
time is 6 hours. Delayed start can be used with this choice,
but not calendar programming.
NOTE! A door contact can be used for all system
types. The contact will detect if the sauna door is
opened after the last sauna has been taken. NB:
timer-controlled systems will require a check of the
sauna and confirmation on the control panel.
8. Enter Sauna time limit (maximum time depends on system
type).
9. Enter Door contact (Yes, No).
10. Enter No at Automatic filling and emptying (automatic wa-
ter filling and emptying - applies to the Expression heater).
The control panel in general
The control panel is automatically activated when you pass your
hand over it.
Use UP (see Figure 3Figure 5, Page 2 pos 6) and
DOWN(pos 9) to scroll through the menus.
Use UP and DOWN to increase/decrease a value when entering
data.
Confirm menu choices using OK (pos 8).
12
11
13 14 15
19
20
Figure 3: Main menu
1. ON/OFF
2. TEMPERATURE
3. HUMIDITY: Set humidity
4. TIMER: Program start time
5.
SETTINGS
6. STATUS BAR: Shows the status of certain functions
(13-20)
7. UP: One step up in the menu or increase value when enter-
ing data
8. LIGHT
9. OK: Confirm choice
10. DOWN: One step down in the menu or decrease value
when entering data
11. BACK: Go one step back in the menu or when entering
data
12. HOME: Return to main menu
13. ON/OFF STATUS: Shows that the sauna/steam bath is on
14. LIGHT STATUS: Shows that the light is on
15. TIMER STATUS: Shows that the control panel is pro-
grammed for delayed start
16. CALENDAR STATUS: Shows that the system is calen-
dar-programmed
17. HUMIDITY STATUS: Shows approximate reservoir level
Full symbol = full reservoir, half-full symbol = half reservoir
and flashing empty symbol = empty reservoir. Only applies
to heaters with manual water filling.
18. LOCKED STATUS: Shows that the panel is locked
19. DRYING STATUS: Shows that the system is in Dryingset-
ting, replaces ON/OFF STATUS
20. STANDBY STATUS: Shows that the system is in Stand-
bysetting, replaces ON/OFF STATUS
1
2
3
4
5
6
7
8
OK
9
10
16 17 18
