Key To Product Code; Decals Applied To The Product; Model Identification - Zenit UNIQA Anleitung Für Die Installation

1.10 Product's name description
Model
1
Product designation
ZU = Zenit UNIQA
2
Construction material
G = Cast iron
B = Bronze
X = Stainless steel
3
Type of impeller
OC = open channel
CC = closed channel
V = vortex
GR = Grinder
HP = High head
CP = Channel with chopper system
Version
13
Construction materials
and coating
14 Electrical accessories

1.11 Decals applied to the product

Fig. 2a page 69 - Decal identifying surfaces with high temperature risk
Fig. 2b page 69 - Decal indicating correct impeller rotation direction (viewed from above)
Fig. 3a page 69 - Silver sticker. Reproduces the nameplate affixed to the product. it must be stuck into the space provided in this manual and
be referred to when making any requests or enquiries.
Fig. 3b page 69 - Sticker applied to the production packaging

1.12 Model identification

To identify a model based on its accessories and admissible installations, Zenit uses the abbreviation relative to motors with power P2 and poles,
as stated in the table below:
Type P2 (kW) - AW version
4/2 ÷ 5.5/2
M08S 3/4
1.5/6 ÷ 1.8/6
7.5/2 ÷ 11/2
M08L 4/4 ÷ 5.5/4
2.2/6 ÷ ÷ 3/6
7.5/4
M10S
4/6
15/2 ÷ 18.5/2
M10L
9/4
5.5/6
22/2 ÷ 30/2
M12N 11/4 ÷ 15/4
7.5/6 ÷ 11/6
37/2 ÷ 45/2
M13N 18.5/4 ÷ 30/4
15/6 ÷ 18.5/6
37/4 ÷ 45/4
M15N 22/6 ÷ 37/6
15/8 ÷ 18.5/8
55/4 ÷ 75/4
M17N 45/6 ÷ 55/6
22/8 ÷ 30/8
90/4 ÷ 110/4
M21S 75/6 ÷ 90/6
37/8 ÷ 55/8
132/4 ÷ 160/4
M21L 110/6 ÷ 132/6
65/8
ZUG V 100 A 15/2 A W 160 X A
1 2 3 4 5
AA BA 10 4Y 5T1 EX NN
13 14 15
- hydraulic
- shaft
WET (W) version
P2 (kW) - HW version
5.5/2 ÷ 7.5/2
9/2 ÷ 13/2
5.5/4 ÷ 7.5/4
7.5/4 ÷ 9/4
18.5/2 ÷ 22/2
11/4
25/2 ÷ 37/2
13/4 ÷ 18.5/4
9/6 ÷ 13/6
22/4 ÷ 37/4
18.5/6 ÷ 22/6
-
45/6 ÷ 65/6
-
185/4 (No Ex)
6 7 8
9 10
4
Outlet diameter in mm
5
Hydraulic variant
6
Power in kW
7
Motor poles
8
Motor variant
9 Operating mode
D = dry
W = wet
10 Nominal diameter of impeller (in mm)
Type of installation
11
Holes for installation/accessories
12
16 17 18 19
Cable length (m)
15
Voltage
16
Frequency/phases
17
Special version/certification
18
19
Customization
P2 (kW) - AD version
-
4/2 (No Ex)
7.5/2 ÷ 11/2
4/4 ÷ 7.5/4
4/6
15/2 ÷ 18.5/2
9/4
5.5/6
22/2 ÷ 30/2
11/4 ÷ 15/4
7.5/6 ÷ 11/6
37/2 ÷ 45/2
18.5/4 ÷ 30/4
15/6 ÷ 18.5/6
37/4 ÷ 45/4
22/6 ÷ 37/6
15/8 ÷ 18.5/8
55/4 ÷ 75/4
45/6 ÷ 55/6
22/8 ÷ 30/8
90/4 ÷ 110/4
75/6 ÷ 90/6
37/8 ÷ 55/8
132/4 ÷ 145/4 (160/6 No Ex)
110/6 ÷ 132/6
65/8
First installation manual – Translation of original instructions
11 12
DRY (D) version
P2 (kW) - HD version
-
-
9/2 ÷ 13/2
5.5/4 ÷ 9/4
18.5/2 ÷ 22/2
11/4
25/2 ÷ 30/2 (37/2 No Ex)
13/4 ÷ 18.5/4
9/6 ÷ 13/6
22/4 ÷ 37/4
18.5/6 ÷ 22/6
-
45/6 ÷ 65/6
-
-
