Disinfection; Sterilization - Welch Allyn KleenSpec 78812 Gebrauchsanweisung

Soak
Refer to Cleaning Table to identify the appropriate cleaning product.
Illuminator (REF 78800) and/or Expendable Illuminator (REF 78600)
1. Disconnect the transformer from the wall outlet and then disconnect the illuminator
from the transformer.
2. Disconnect illuminator from expendable illuminator and remove the expendable
illuminator from the speculum (58600 / 58601 only).
Lamp must remain installed during all cleaning and disinfection processes.
3. Follow the cleaning solution manufacturer's instructions and soak the illuminator and/or
expendable illuminator as instructed. Solution temperature is 22° C to 43° C.
4. Scrub any area of visible debris with a soft brush and thoroughly rinse the illuminator
and/or expendable illuminator with 22° C to 43° C tap water to remove the cleaning
solution.
5. Rough dry the illuminator and/or expendable illuminator.
6. The illuminator and/or the expendable illuminator is now ready for disinfection.
Limited Soak
Power Supply
Refer to Cleaning Table to identify the appropriate cleaning product.
1. Disconnect the power supply from the wall outlet and then disconnect the illuminator
from the power supply.
2. Follow the cleaning solution manufacturer's instructions and soak the cord only in the
solution as instructed. Solution temperature is 22° C to 43° C.
3. Scrub any area of visible debris with a soft brush and thoroughly rinse power supply
cord only with 22° C to 43° C tap water to remove the cleaning solution.
4. Rough dry power supply.
5. The power supply is now ready for disinfection.

Disinfection

Refer to the Cleaning Table to identify the appropriate disinfection method/product for the
illuminator, expendable illuminator, and/or power supply.
Illuminator (REF 78800) and/or Expendable Illuminator (REF 78600)
1. Clean illuminator and/or expendable illuminator as instructed in "Cleaning-Soak" or
"Cleaning-Wipe".
2. Follow the disinfecting wipe manufacturer's disinfection instructions.
3. Thoroughly rinse illuminator and/or expendable illuminator with 22° C to 43° C tap
water to remove disinfectant.
4. Allow to dry.
Power Supply
DO NOT IMMERSE THE POWER SUPPLY PLUG.
1. Clean power supply as instructed under "Cleaning-Limited Soak" or "Cleaning-Wipe".
2. Follow the disinfecting wipe manufacturer's disinfection instructions on the cord only.
3. Thoroughly rinse the cord only with 22° C to 43° C tap water to remove disinfectant.
4. Allow to dry.

Sterilization

Refer to the Cleaning Table to identify the appropriate sterilization method/product for the
illuminator, expendable illuminator.
1-5
