Approvals

CERTIFIED TO: CAN/CSA STD C22.2 NO. 601.1
CONFORMS TO: IEC 60601-1, IEC60601-1-2, UL STD 2601-1
The CE Mark on this product indicates it has been tested to and conforms
with the provisions noted with the 93/42/EEC Medical Device Directive.
Regulatory Affairs Representative
Welch Allyn Limited
Navan Business Park
Dublin Road
Navan, County Meath, Republic of Ireland
Australia EMC Framework Compliant

Trouble Shooting Guide

Problem
Power switch is in the off
position.
Illuminator is not plugged
into the power supply.
Power supply is not plugged
in.
Lamp does not Faulty Lamp
light.
Loose Lamp
Wrong Lamp
Damaged Lamp
Illuminator does
not stay retained
into 580 series Possible damage to the
specula or 78600 illuminator retention wings.
expendable
illuminator.
Possible Cause
Verify the power switch is in the on
position. Refer to manual.
Verify that the illuminator is properly
plugged into power supply cord.
Verify the power supply is properly
plugged into the outlet.
Replace with a new lamp.
Verify that the lamp is secured into the
illuminator.
Verify that the lamp is a REF 08800
Welch Allyn lamp.
Inspect the lamp and the o-ring for
damage. Replace with REF 08800
lamp if damage is found.
Inspect retention wings for damage.
Replace illuminator REF 78800.
1-7
Solution
