CAUTION: Use only the cleaning methods and disinfection solutions/methods
described in this manual. Clean the device prior to disinfection.
CAUTION: The Illuminator (REF 78800) is a biohazard after use. Follow good
hospital practices and the instructions for cleaning and disinfection of the
illuminator within this manual prior to the next usage.
CAUTION: Ensure lamp is installed and fully seated in illuminator throughout
cleaning and disinfection process. The illuminator assembly is immersible
(IPX7) provided the lamp is properly installed.
Illuminator is capable of temporary immersion to a depth of .15 to 1 meter, at
ambient pressure, at room and fluid temperatures of 22° C to 43° C.
There are no user-serviceable parts inside the device except the lamp. Contact
the Authorized Service Center listed on page 10.
WARNING: KleenSpec Vaginal Specula Illumination System is not suitable for
use in the presence of a flammable anesthetic mixture with air or oxygen or
nitrous oxide. An explosion may result.
This device complies with current required standards for electromagnetic
interference, and should not present problems to other equipment or be
affected by other devices. As a precaution, avoid using this device in close
proximity to other equipment.
To remove all power from the Vaginal Illumination System, unplug the external
power supply from the wall outlet.

Instructions for Use

KleenSpec Vaginal Specula Illumination System

The KleenSpec Vaginal Specula Illumination System, consisting of the illuminator and
power supply are designed to work with the following Welch Allyn specula: 58000, 58001,
58004, 58000S, 58001S, 58004S, 58005, 58006, and 58600 / 58601 (with expendable
illuminator 78600) for gynecological and obstetric procedures.
The power supply plug provides power from the hospital-grade wall outlet to the illuminator
assembly (REF 78800) which houses the lamp (REF 08800). This provides illumination to
the specula and expendable illuminator (see above). This device is intended for use only
with appropriate accessories (see above).
This product is for use with the Welch Allyn KleenSpec Single-Use Vaginal Specula only. Do
not use the illuminator for any other use. Lamp is hot and can cause a burn if used outside
of the vaginal specula.
Assemble the power supply to the illuminator as shown below. The illuminator then slides
into the appropriate Welch Allyn accessory listed above. Verify all connections are made
prior to applying power with the on/off switch.
