10

Maintenance

<Daily maintenance>
▼ Cleaning of air filter
If is displayed on the remote controller, maintain the
air filter.
1
Push the button to stop the
operation, then turn off the circuit breaker.
4
2
Take out the air filter.
• Push down hook of the air filter on the front
panel (Lower side).
• Pull the air filter toward you to remove it.
Front panel (Lower)
Air filter knob
• Cleaning with water or vacuum cleaner
• If dirt is heavy, clean the air filter by tepid
water with neutral detergent or water.
• After cleaning with water, dry the air filter
sufficiently in a shade place.
• Mount the air filter.
3
Turn on the circuit breaker, then push the
button on the remote controller to
start the operation.
4
After cleaning, push .
display disappears.
109-EN
CAUTION
• Do not start the air conditioner while leaving air filter
removed.
• Push the filter reset button. ( indication will be turn
off.)
▼ Periodic Maintenance
For environmental conservation, it is strongly
recommended that the indoor and outdoor units of the
air conditioner in use be cleaned and maintained
regularly to ensure efficient operation of the air
conditioner.
1, 3
When the air conditioner is operated for a long time,
periodic maintenance (once a year) is recommended.
Furthermore, regularly check the outdoor unit for rust
and scratches, and remove them or apply rustproof
treatment, if necessary.
As a general rule, when an indoor unit is operated for 8
hours or more daily, clean the indoor unit and outdoor
unit at least once every 3 months. Ask a professional
for this cleaning / maintenance work.
Such maintenance can extend the life of the product
though it involves the owner's expense.
Failure to clean the indoor and outdoor units regularly
will result in poor performance, freezing, water
leakage, and even compressor failure.
– 55 –
▼ Inspection before maintenance
Following inspection must be carried out by a qualified installer or qualified service person.
Parts
Access from inspection opening and remove the access panel. Examine the heat exchanger if there
Heat exchanger
is any clogging or damages.
Fan motor Access from inspection opening and check if any abnormal noise can be heard.
Access from inspection opening and remove the access panel. Examine the fan if there are any
Fan
waggles, damages or adhesive dust.
Filter Go to installed location and check if there are any stains or breaks on the filter.
Access from inspection opening and remove the access panel. Check if there is any clogging or drain
Drain pan
water is polluted.
▼ Maintenance List
Part Unit
Heat exchanger Indoor / outdoor
Fan motor Indoor / outdoor
Filter Indoor
Fan Indoor
Air intake / discharge
Indoor / outdoor
grilles
Drain pan Indoor
Ornamental panel,
Indoor
louvres
Exterior Outdoor
Inspection method
Check (visual / auditory) Maintenance
Wash the heat exchanger when it is
Dust / dirt clogging, scratches
clogged.
Take appropriate measures when
Sound
abnormal sound is generated.
• Wash the filter with water when it is
contaminated.
Dust / dirt, breakage
• Replace it when it is damaged.
• Vibration, balance • Replace the fan when vibration or
balance is terrible.
• Dust / dirt, appearance
• Brush or wash the fan when it is
contaminated.
Fix or replace them when they are
Dust / dirt, scratches
deformed or damaged.
Dust / dirt clogging, drain Clean the drain pan and check the
contamination downward slope for smooth drainage.
Wash them when they are contaminated
Dust / dirt, scratches
or apply repair coating.
• Rust, peeling of insulator
Apply repair coating.
• Peeling / lift of coat
110-EN
