Pin Belegung
11 Busy
12 PError
13 Select
14 nAutoFd
15 Not connected
16 Logic Gnd
17 Not connected
18 Not connected, optional + 5V
19 Signal Ground
20 Signal Ground
21 Signal Ground
22 Signal Ground
23 Signal Ground
24 Signal Ground
25 Signal Ground
26 Signal Ground
27 Signal Ground
28 Signal Ground
29 Signal Ground
30 Signal Ground
31 nInit
32 nFault
33 Signal Ground
34 Signal Ground
35 Not connected
36 nSelectIn
Pinbelegung der Centronics Schnittstelle 36 polig
Ein- oder Ausgang
IN
IN
IN
OUT
-
-
-
-, optional external power supply from printer
-
-
-
-
-
-
-
-
-
-
-
-
OUT
IN
-
-
-
OUT
