TECHNICAL CHARACTERISTICS

Power supply (L-N)
Rated power
Photocell power supply output
Flashing light output
Courtesy light output
Electric lock output
Gate open warning light output
Antenna input
Operating temperature
Accessory fuses
Power supply line fuses
Use in particularly acid,
saline or explosive atmospheres
Protection class
Control unit dimensions
Weight
* Compulsory for motors: RAY4024E, SN-50-24 and UND24 when in two-leaf configuration

2.4 - List of cables required

The cables required for connection of the various devices in a
standard system are listed in the cables list table.
ELECTRIC CABLE TECHNICAL SPECIFICATIONS
Connection
Power line
Flashing light, Courtesy light, ambient light sensor
Antenna
Electric lock
Transmitter photocells
Receiver photocells
Sensitive edge
Key-operated selector switch
Motor power supply line
Encoder power supply line
* If the power supply cable is more than 20 m long, it must be of larger gauge (3x2.5mm
near the automation unit.
** Two cables of 2 x 0.5 mm
2

3 - PRELIMINARY CHECKS

Before installing the product, perform the following checks and
inspections:
check that the gate is suitable for automation;
the weight and size of the gate must be within the operating limits
specified for the automation system in which the product is installed;
check that the gate has firm, effective mechanical safety stops;
make sure that the product fixing zone is not liable to flooding;
high acidity or salinity or proximity to heat sources might cause the
product to malfunction;
in case of extreme weather conditions (e.g. snow, ice, wide
temperature variations or high temperatures), friction may increase,
causing a corresponding rise in the force needed to operate the
system; the starting torque may therefore exceed that required in
230Vac (+10% - 15%) 50/60 Hz
maximum 210W
24Vdc (without regulation) maximum 250mA 24Vdc (without regulation) maximum 250mA
24Vdc (without regulation) 25W
24Vdc (without regulation) 15W
12Vac maximum 15VA
24Vdc (without regulation) 5W
50Ω RG58 type cable
-20 °C + 55 °C
2.5AT
2AT
NO
IP54 (inside protective casing)
183 x 102 x 59 H mm
4,3 kg
can be used as an alternative
230Vac (+10% - 15%) 50/60 Hz
maximum 300W
24Vdc (without regulation) 25W
24Vdc (without regulation) 15W
12Vac maximum 15VA
24Vdc (without regulation) 5W
50Ω RG58 type cable
-20 °C + 55 °C
2.5AT
2AT
NO
IP54 (inside protective casing)
183 x 102 x 59 H mm
4,5 kg
The cables used must be suitable for the type of installation; for
example, an H03VV-F type cable is recommended for indoor
applications, while H07RN-F is suitable for outdoor applications.
cable
1 cable of 3 x 1.5 mm
2
4 x 0.5 mm **
2
1 RG58 type cable
1 cable of 2 x 1 mm
2
1 cable of 2 x 0.5 mm
2
1 cable of 4 x 0.5 mm
2
1 cable of 2 x 0.5 mm
2
1 cable of 4 x 0.5 mm **
2
1 cable of 2 x 1.5 mm
2
1 cable of 3 x 0.5 mm
2
) and a safety grounding system must be installed
2
normal conditions;
check that, when operated by hand, the gate moves smoothly
without any areas of greater friction or derailment risk;
check that the gate is well balanced and will therefore remain
stationery when released in any position;
check that the electricity supply line to which the product is to be
connected is suitably earthed and fitted with magnetothermal and
differential protection;
the system power supply line must include a circuit breaker
device with a contact gap allowing complete disconnection in the
conditions specified by class III overvoltage;
ensure that all the material used for installation complies with the
relevant regulatory standards.
maximum permitted limit
20 m *
20 m
20 m (< 5 m recommended)
10 m
20 m
20 m
20 m
20 m
10 m
10 m
EN
19
