Technical Data - Sentiotec A2-15 Montage- Und Gebrauchsanweisung

Technical Data:

Ambient temperature:
Storage temperature:
Minimum temperature stability
of the connecting lines:
Heating system, light and temperature sensors
at least 150 °C of temperature stability
Sauna control:
Dimensions (Wx H x D): 240 x 80 x 220 mm
Type of protection: IP X4 - protection from splashing
water
Weight: approx. 1250 g
Nominal voltage: 400 VAC; 50/60 Hz; 3N
Switching capacity:
min. / max. pick-up capacity:
Connection to the main circuit as permanent wiring
(non-detachable connection).
Range of adjustment:
Temperature 50 - 125 degrees Celsius
(refers to sensor location FI)
Light: 230 V, AC1:
max. switching capacity: 230 W
Operating instructions for the user
-10 °C to + 40 °C
-25 °C to + 70 °C
AC1, 3 x 5.0 kW
4,3 / 6,3 VA
1A
Edition: 05-2012 Ident-Nr. 50950021
27
