Inner Door Instruction Label - Agilent Technologies 947 Betriebs- Und Servicehandbuch

Models 947, 948 and 960 Leak Detectors Operations and Service Manual

1.4 Inner Door Instruction Label

The label on the inside of the lockable turret door (Figure 1-4) provides:
An abbreviated list of leak detector operating instructions to be used when the
operator is familiar with normal operation of the 947/948/960.
Error codes and solutions.
The leak detector's standard leak setting as measured at the factory.
Figure 1-4 Turret Door Instruction Label
1-9
