4) until the highest step is below rod K (Fig. 4).
Make the fi rst cut on the material. Turn the turret
Q to the next step and then make another cut, and
so on until the required depth is obtained when the
bottom step is reached.
9. LOCKING THE ROUTING DEPTH
To carry out several repetitive jobs in which the
same router depth is required, it may be useful to
prevent the head being released by accidentally
moving the locking knob J (Fig. 1). This may be
done by inserting two M8 nuts R (Fig. 4) in the
threaded shaft, one above and one below the
head body. This locks the head at any point along
its depth setting.
WARNING! When working with the depth locked,
the tool is permanently held outside the surface of
the base, so it is important to:
- Wait for the machine to stop completely before
leaving it on the base, on a fl at surface which
leaves the tool free.
- Cancel the locked depth and return to the normal
conditions of locking by the knob J (Fig. 1) as soon
as the task has been completed.
10. USE OF PARALLEL GUIDE
Parallel guide is used for edge trimming and cutting
differently shaped grooves in accordance with
various profi le shapes.
Parallel guide S (Fig. 6) is placed in base grooves
T (Fig. 6) and secured in place using the two knobs
U (Fig. 6).
NORMAL SQUARE ADJUSTMENT – Loosen the
base knobs, move the square to the required posi-
tion and then tighten the knobs in this position.
PRECISION ADJUSTMENT – Once the square has
been approximately positioned and held in place,
a further fi ne adjustment may be made. To do this,
loosen square fastening knob V (Fig. 6), turn the
fi ne-adjustment knob on guide W (Fig. 6) to the
required measurement, then tighten the square
fastening knob V (Fig. 6) again in this position. A
full turn of the knob moves the square by 1 mm,
with a maximum distance of 10 mm. The gauged
fi ne-adjustment indicator X (Fig. 6) can be moved
separately from the knob, so that it may be set to
zero from any position using the reference mark.
When turning the knob W (Fig. 6) after adjusting
the indicator X (Fig. 6), both elements will turn
together, thereby indicating the degree to which
the square has been moved, with each division
representing an advance of 0.1 mm.
11. USE OF TEMPLATE GUIDES
Template guides are used for copy cutting of richly
shaped patterns. Selected template guide Y (Fig.
7) is fi xed to base T (Fig. 7) using the two screws
Z (Fig. 7). When copying, a diffrence in size bet-
ween the template and the routed item becomes
apparent. The difference between the radius of
the template guide and the radius of the tool must
always be taken into account when preparing the
template.
12. DUST COLLECTOR ATTACHMENT
To attach the dust collector connector A1 (Fig. 6),
place it in the central recess in base T (Fig. 6),
with the connection facing the back, and hold it in
place with screws B1 (Fig. 6). The dust collector
connector A1 may be attached either directly to the
suction tubes of dust collectors AS182K, AS282K
or by using the smaller diameter and lighter
6446073 standard dust collector attachment, C1
(Fig. 6), which can then be attached to AS182K,
AS282K or any other industrial dust collector.

13. CHANGING THE BRUSHES

WARNING! Disconnect the machine from the mains
before performing any maintenance operations.
The brushes must be replaced when they reach
the minimum length of 5 mm. For this purpose,
remove the switch box A (Fig. 6) by removing the
screws which hold it in place. Remove plugs D1
(Fig. 8) which hold brushes E1 (Fig. 8) and replace
them with new original VIRUTEX brushes, ensu-
ring that they slide smoothly through the guides.
We recommend running the unloaded machine
for several minutes after changing the brushes.
Take the opportunity to check the condition of the
collector. If it shows signs of burning or wear and
tear, we recommend bringing it to a VIRUTEX tech-
nical service centre for repair. When reassembling
switch box A, take care to ensure that the cables
are properly located inside it.
14. LUBRITATION AND CLEANING
The machine is delivered fully lubricated from the
factory and does not require any special care during
its working life. It is important to clean the machine
carefully after use, using a dry air jet.
Maintain the supply cable in perfect operating
conditions.

15. OPTIONAL ACCESSORIES

The following optional accessories may be su-
pplied:
5000000 Dovetailing template PL11
6027020 Chuck Ø 6
6727020 Chuck Ø 1/4"
6446073 3.5 m Standard dust collector attach-
ment.
Template guides:
7
