3-16
[378]: This option allows the parallel port to use 378 as its I/O port address. The majority of parallel ports
on computer systems use IRQ7 and I/O Port 378H as the standard setting.
[278]: This option allows the parallel port to use 278 as its I/O port address.
[3BC]: This option allows the parallel port to use 3BC as its I/O port address.
Parallel Port Mode:
This item specifies the parallel port mode.
[Normal]: Allows the standard parallel port mode to be used.
[SPP]: (Standard Parallel Port) Allows bi-directional parallel port operation at normal speed.
[EPP]: (Enhanced Parallel Port) Allows bi-directional parallel port operation at maximum speed.
[ECP]: (Extended Capabilities Port) Allows bi-directional parallel port operation at a speed faster than
the normal mode's data transfer rate.
EPP Mode Select:
This item selects the EPP mode.
ECP Mode Use DMA:
This item selects the DMA channel of the parallel port.
Onboard PCI Device:
Click <Enter> key to enter its submenu:
IEEE 1394 Controller:
This option enables or disables the IEEE 1394 controller.
Serial ATA Controller:
This option enables or disables the Serial ATA controller of Silicon Image PCI Chip
